Operating manual Clou Compact Cook
Fig. 10: Fixing the hotplate
Fig. 11: Distance from hotplate to body
Fig. 12: Mounting the side cladding
1
Distance between hotplate and body
4,50 mm
2
The distance between the hotplate (1) and the body (2)
must not be less than 4.5 mm.
EN
4) Fix the hotplate to the stove (left and right) from be-
low with two screws each.
NOTICE
5) Mount the rear side cladding. Proceed as described in
the section Mounting the side cladding [}on page
32].
9 | Installation
