- Page 1 Operating manual Clou Compact Cook www.austroflamm.com...
- Page 2 Printing, spelling and typographical errors reserved. The information in this document is subject to change without prior notice and should not be construed as a commitment by Austroflamm GmbH. Austroflamm GmbH assumes no responsibility for any errors that may appear in this document.
-
Page 3: Table Of Contents
Operating manual Clou Compact Cook Contents Contents General information ............................Copyright.............................. Information about the document ...................... Purpose of the manual............................Storing the manual ..........................Structure of the manual........................Representations used.......................... Version control ............................. Abbreviations ............................Safety..................................Importance of the safety instructions .................... - Page 4 Contents Operating manual Clou Compact Cook 9.1.3 Mounting the flue pipe connection at the top ................. 26 9.1.4 Mounting the flue pipe bracket at the back ..................27 9.1.5 Installing the HMS..........................29 9.1.6 Installing Keramott..........................30 9.1.7 Installing the air supply adapter ......................31 9.1.8...
-
Page 5: General Information
Information about the document The information in this document is subject to change without prior notice and should not be con- strued as a commitment by Austroflamm GmbH. Austroflamm GmbH assumes no responsibility for any errors that may appear in this document. -
Page 6: Purpose Of The Manual
2 | Purpose of the manual Operating manual Clou Compact Cook Purpose of the manual This manual is a component part of the stove and is intended to contribute to the stove being safely in- stalled and maintained. Please read this manual before using the stove for the first time. -
Page 7: Version Control
Operating manual Clou Compact Cook 2 | Purpose of the manual Version control We update our manuals on a continual basis. The current version can be found at our homepage www.austroflamm.com. Abbreviations Abbreviation Meaning Hotplate connection at rear (without hole for flue pipe,... -
Page 8: Safety
• Before operating your stove, carefully read through the entire manual and observe the instructions and warnings. • Austroflamm GmbH accepts no liability or responsibility for the connection of our heating appli- ances to shared exhaust pipes/chimneys – multiple occupancy. For more information consult a chimney sweep and check your national, regional and local building regulations. -
Page 9: Special Types Of Danger And Personal Protective Equipment
Operating manual Clou Compact Cook 3 | Safety • Please note that the surfaces of this stove heat up considerably during operation. We recommend that you use the protective glove supplied to operate your stove. • Please alert children to these dangers, and keep them away from the stove when it is operating. -
Page 10: Product Overview
4 | Product overview Operating manual Clou Compact Cook Product overview Intended use The Austroflamm stove described in this manual is manufactured and tested with a type A1 self-closing and locking door under EN 13240. NOTICE Operation is only permissible with closed/bolted door. -
Page 11: Energy Label
Operating manual Clou Compact Cook 4 | Product overview 1) Open (+) and closed (-) (primary/secondary air control- ler) Fig. 2: Air control Energy label -80% Austrof amm CLOU COMPACT COOK -60% -40% -20% 11,3 ENERGIA · ЕНЕРГИЯ · ΕΝΕΡΓΕΙΑ · ENERGIJA · ENERGY · ENERGIE · ENERGI 2015/1186 Fig. 3: Energy label... -
Page 12: Positioning Of The Type Plate
4 | Product overview Operating manual Clou Compact Cook Positioning of the type plate Here we show where you can find the type plate. You received a copy of the type plate with the stove. You can find a copy of the type plate of your stove on the back of the manual you get with your stove. -
Page 13: Technical Data
Operating manual Clou Compact Cook 5 | Technical data Technical data As a type 1 stove, a connection to a chimney already occupied with other solid-fuel stoves and ovens is possible provided that the chimney rating under DIN 4705 – part 3, does not contravene this. - Page 14 5 | Technical data Operating manual Clou Compact Cook Particular precautions for assembly, installation or maintenance Described in the individual sections of the operating manual. Fuel Preferred Other suit- Space heating emis- Space heating emis- ηs fuel able fuel(s) [x%]:...
- Page 15 Operating manual Clou Compact Cook 5 | Technical data Properties for exclusive operation with the preferred fuels Specification Symbol Value Unit Specification Symbol Value Unit Heat output Thermal efficiency (fuel efficiency) (based on the NCV) Nominal heat effi- Pnom Thermal efficiency (fuel ef- 78.2...
-
Page 16: General Specifications
Baking compartment depth [mm] Warming drawer, width [mm] Warming compartment height [mm] Warming drawer, depth [mm] Dimensions, a (with Austroflamm elbow piece) [mm] 1601 Dimensions, b (with Austroflamm elbow piece) [mm] Dimensions, c (with Austroflamm elbow piece) [mm] Dimensions, d (with Austroflamm elbow piece) [mm] Flue pipe outlet, diameter [mm] Outside air connection diameter [Ø mm]... -
Page 17: Transport, Handling And Storage
Operating manual Clou Compact Cook 6 | Transport, handling and storage Transport, handling and storage Transportation Immediately checked the goods delivered for complete- ness and damage in transit. Before installing the stove, check that all movable parts are working. Any defects before the installation of the stove must be reported. -
Page 18: Requirements At The Installation Location
Safety distances to be observed If your floor is made of a combustible material, a non-combustible material must be used as protection in the area in front of the appliance. For more detailed information, please contact an Austroflamm dealer. NOTICE A floor protection plate must be used if your floor is made from a combustible material. -
Page 19: Combustion Air
When connecting the flue pipes to the chimney, national and/or local safety regulations must be com- plied with. Your Austroflamm stove is fitted at the factory with a flue pipe outlet at the top (see chapter Technical data). The connection can, as described in these instructions, be rearranged to the bottom. -
Page 20: Fuel Material/-Quantity
8 | Fuel material/-quantity Operating manual Clou Compact Cook Fuel material/-quantity Fuel Wood Many of our native types of wood can, after being appropriately dried, be burnt CO2-neutral in heat- producing appliances. Wood stands out because it grows again, can be sustainably harvested, re- quires little or no extra external energy to be invested in the fuel, and has a short journey from the pro- ducer to the consumer, which provides an optimal climate balance. - Page 21 Operating manual Clou Compact Cook 8 | Fuel material/-quantity Please observe at all times the maximum specified amount to be laid, even when putting on more wood! Otherwise your fire will not provide the desired efficiency - but above all considerable damage may be caused to your appliance, to gaskets and material and to the flue gas duct.
-
Page 22: Fuel Quantity
Maximum amount of fuel to be deposited: 1,7 kg NOTICE Overheating Too great a quantity of fuel can lead to overheating and damage to your Austroflamm stove NOTICE To avoid damage you must NEVER operate your Stove a greater quantity of fuel than that specified in... -
Page 23: Installation
Operating manual Clou Compact Cook 9 | Installation Installation Installation must only be carried out by an authorized specialist company. Before installing the stove, check that all movable parts are working. Any defects must be reported be- fore the installation. -
Page 24: Mounting Top Flue Connection + Rear Flue Connection Hotplate
If the seal is damaged, not correctly positioned or the silicone has come loose, have it replaced/adjus- ted by an Austroflamm dealer or Austroflamm service technician. Fig. 8: Check the seal 3) Attach the hotplate with the cut-out to the stove. - Page 25 Operating manual Clou Compact Cook 9 | Installation 4) Fix the hotplate to the stove (left and right) from be- low with two screws each. Fig. 10: Fixing the hotplate NOTICE Distance between hotplate and body 4,50 mm The distance between the hotplate (1) and the body (2) must not be less than 4.5 mm.
-
Page 26: Mounting The Flue Pipe Connection At The Top
9 | Installation Operating manual Clou Compact Cook 9.1.3 Mounting the flue pipe connection at the top 1) Check the seal before installing the hotplate AO. Pro- ceed as described in the second step in the section Mounting the hotplate [}on page 24]. -
Page 27: Mounting The Flue Pipe Bracket At The Back
Operating manual Clou Compact Cook 9 | Installation 9.1.4 Mounting the flue pipe bracket at the back 1) If the rear side cladding is mounted, it must first be dismounted. Proceed as described in the section Re- moving the side cladding [}on page 49]. - Page 28 9 | Installation Operating manual Clou Compact Cook 4) Use side cutters to remove the perforated cut-out. Fig. 17: perforates Break out the cutout 5) Remove cover from the back. Fig. 18: Removing cover from the back 6) Mount flue pipe bracket with sealing ring at the back.
-
Page 29: Installing The Hms
Operating manual Clou Compact Cook 9 | Installation 9.1.5 Installing the HMS 1) If the rear side cladding is mounted, it must first be dismounted. Proceed as described in the section Re- moving the side cladding [}on page 49]. 2) Undo screws and remove radiation protection. -
Page 30: Installing Keramott
9 | Installation Operating manual Clou Compact Cook 5) Mount HMS bricks on the holders and fasten at the side with the HMS cable. Fig. 23: Installing the HMS bricks 6) Mount the rear side cladding. Proceed as described in the section Mounting the side cladding [}on page 32]. -
Page 31: Installing The Air Supply Adapter
Operating manual Clou Compact Cook 9 | Installation 9.1.7 Installing the air supply adapter 1) First attach the ring (2) to the supply air adapter (1). 2) Insert the supply air adapter (1) into the stove at the bottom and fix it with the ring to the air connection (3). -
Page 32: Mounting The Side Cladding
9 | Installation Operating manual Clou Compact Cook 9.1.8 Mounting the side cladding 1) Attach side cladding to the stove. Fig. 28: Attaching the side cladding ü On the back of the stove are slots through which the rear side cladding can be fixed. -
Page 33: Settings
Operating manual Clou Compact Cook 10 | Settings Settings 10.1 Aligning the stove 1) First the cover and the side cladding must be de- tached. ð Proceed , as described in the section Removing the side cladding. 2) There are two screw on the back of the stove. These can be used to align the stove. - Page 34 10 | Settings Operating manual Clou Compact Cook 4) Undo screws and removing cladding. Fig. 34: removing upper front cladding 5) Undo the screws at the bottom and remove cladding. Fig. 35: removing lower front cladding...
-
Page 35: Adjusting The Door Lock
Operating manual Clou Compact Cook 10 | Settings 6) The door can be adjusted on the screws. 7) Using the screws (1) the door can be adjusted up, down, left and right. 8) Using the grub screws (2) the door can be adjusted in and out. -
Page 36: Adjusting The Closing Pressure Of The Door
10 | Settings Operating manual Clou Compact Cook 10.4 Adjusting the closing pressure of the door Only the left side cladding needs to be removed for this step. . 1) To remove the cover and the side cladding, Proceed as described in the section Removing the side clad- ding. -
Page 37: Commissioning
Operating manual Clou Compact Cook 11 | Commissioning Commissioning 11.1 Initial Commissioning NOTICE During the initial commissioning and in the following 2-3 combustion cycles, only approx. 2/3 of the maximum fuel quantity is to be used. NOTICE To avoid damage you must NEVER operate your Stove a greater quantity of fuel than that specified in this manual! During the first 3-4 combustion cycles at nominal heat output, odors may develop. -
Page 38: Operation
12 | Operation Operating manual Clou Compact Cook Operation 12.1 Before heating up The stove can only function properly if there is sufficient combustion air coming to the room of installa- tion (the appliance), specially if several firing installations are being operated at the same time. Ensure sufficient air supply before heating up. -
Page 39: Heating In The Transition Period
Operating manual Clou Compact Cook 12 | Operation 7) Close the door. ð It is best to allow the first layer of wood to combust without altering the air damper setting. ð If only the bed of embers is left (no more flames), you can place another layer of log. -
Page 40: Maintenance
13 | Maintenance Operating manual Clou Compact Cook Maintenance Have the maintenance carried out by an Austroflamm dealer or an Austroflamm service engineer. -
Page 41: Cleaning
Operating manual Clou Compact Cook 14 | Cleaning Cleaning 14.1 Cleaning the stove, flue gas ducts and flue pipe The stove, the flue gas ducts and flues should be annually - possible even more often, e.g. • after the chimney has been cleaned •... - Page 42 14 | Cleaning Operating manual Clou Compact Cook 1) Open the door. 2) Raise the grate with the attached hook. Fig. 43: Raising the grate 3) Take the lid provided and use it to cover the ash box. 4) Turn the handle of the lid clockwise until the handle engages.
-
Page 43: Cleaning The Door Window
14.4 Cleaning the door window Spray window with glass cleaner and leave it for a moment to take effect. • We recommend cleaning the glass with our Austroflamm glass cleaner or a commercially available window cleaner. • Prevent door- or window seals from coming into contact with water or cleaner, since these will oth- erwise harden and in doing so lose their function. -
Page 44: Help
15 | Help Operating manual Clou Compact Cook Help Problem Cause Solution The glass window is sooty Insufficient draft from time to time (depending on use) the window must be cleaned with glass cleaner Clarification with chimney sweeper (poss extend chimney/measure... -
Page 45: Firebox Lining
Operating manual Clou Compact Cook 15 | Help Problem Cause Solution Operating temperature not reached Bring stove to the operating temper- ature Sooting up of the window after 8- 10 hours of fires is normal Chimney draft too low Contact chimney sweep 15.1 Firebox lining... -
Page 46: Accessories
16 | Accessories Operating manual Clou Compact Cook Accessories Have defective parts (accessories, spare parts) replaced by your specialist stove dealer. This guaran- tees that stove is and remains safe and functional. Item no. Quantity Article Article no. Clou Compact Cook... - Page 47 Operating manual Clou Compact Cook 16 | Accessories Keramott Item no. Quantity Article Article no. Baffle plate 1 724088 Keramott floor front 724059 Keramott floor left 724051 Keramott floor right 724056 Keramott floor rear 724052 Keramott panel left 724053 Keramott panel side...
-
Page 48: Spare Parts
17 | Spare parts Operating manual Clou Compact Cook Spare parts Spare parts can be ordered through our dealers. -
Page 49: Disassembling
Operating manual Clou Compact Cook 18 | Disassembling Disassembling For correct uninstallation and dismantling of the stove, contact your Austroflamm specialist dealer. 18.1 Removing side cladding ü On the back of the stove are slots through which the screws can be loosened. - Page 50 18 | Disassembling Operating manual Clou Compact Cook 8) Remove lower front cladding. Fig. 51: Removing lower front cladding...
-
Page 51: Disposal
NOTICE For correct uninstallation and dismantling of the stove, contact your Austroflamm specialist dealer. Electric and electronic components Remove the electric and electronic components from the appliance by dismounting them. These com- ponents must not be disposed of via non-recyclable waste. - Page 52 19 | Disposal Operating manual Clou Compact Cook Handles and decorative elements made of metal If present, disassemble or remove handles and decorative elements made of metal and dispose of as metal scrap. Local disposal options must be observed.
-
Page 53: Guarantee / Warranty
For the replaceability of the warranty case the start-up log must be received by Austroflamm within one month at the latest of the initial commissioning. In or- der to make a claim on the warranty, repairs to your stove must only be carried out by a service en- gineer authorized by Austroflamm. -
Page 54: Start Up Log
21 | Start up log Operating manual Clou Compact Cook Start up log Operator / Customer Dealer / Engineer Name Company Street Street Town and postal code Town and postal code Telephone Telephone Email Email Stove Working Comments Model Serial number... -
Page 55: Service Report
Operating manual Clou Compact Cook 22 | Service Report Service Report Date Technicians Notes Work carried out, replacement parts installed... - Page 56 22 | Service Report Operating manual Clou Compact Cook Date Technicians Notes Work carried out, replacement parts installed...
- Page 57 Notizen / notes / appunti / remarques...
- Page 58 AUSTROFLAMM GMBH Austroflamm-Platz 1 A- 4631 Krenglbach Tel: +43 (0) 7249 / 46 443 www.austroflamm.com info@austroflamm.com 945055...
