9 | Installation
9.1.3

Mounting the flue pipe connection at the top

Fig. 13: Attaching the hotplate
Fig. 14: Distance from hotplate to body
26
1
Distance between hotplate and body
4,50 mm
2
The distance between the hotplate (1) and the body (2)
must not be less than 4.5 mm.
EN
1) Check the seal before installing the hotplate AO. Pro-
ceed as described in the second step in the section
Mounting the hotplate [}on page 24].
2) Attach the hotplate with the cut-out to the stove.
NOTICE
