7 | Requirements at the installation location

7 Requirements at the installation location
7.1

Safety distances to be observed

If your floor is made of a combustible material, a non-combustible material must be used as protection
in the area in front of the appliance. For more detailed information, please contact an Austroflamm
dealer.
NOTICE
A floor protection plate must be used if your floor is made from a combustible material.
Safety distances for combustible objects, such as wooden furniture, upholstered furniture, sofas, etc.
must be complied with. In the case of very heat-sensitive objects the distance from the stove must be
increased in order to avoid damage from the heat.
Please refer to the table below for the necessary safety distances.
1
2 3
6
4
5
dP
2
5
1 Floor
3 Irradiated area
5 Irradiated area to be protected
dP Radiation front [mm]
dS1 Distance left [mm]
dR Distance rear [mm]
dS2 Distance right [mm]
dB Distance bottom [mm]
dF Radiation to the floor [mm]
dL 1 Radiation left [mm]
dL 2 Radiation right [mm]
dC Distance above [mm]
Minimum distance from non-flammable materials [mm]
18
6
3
dF
4
EN
dR
1
2 Fuel front
4 Floor protection plate
6 Fuel area front/side/back
Operating manual Clou Compact Cook
dL
1
5
3
dP
4
dL
2
Clou-Compact-Cook
1050
150
150
150
0
under examination
under examination
under examination
750
50
6
dR
