5 | Technical data
5.2

General specifications

Dimensions and weight
Height [mm]
Width [mm]
Depth [mm]
Combustion chamber width [mm]
Combustion chamber height [mm]
Combustion chamber depth [mm]
Baking compartment width [mm]
Baking compartment height [mm]
Baking compartment depth [mm]
Warming drawer, width [mm]
Warming compartment height [mm]
Warming drawer, depth [mm]
Dimensions, a (with Austroflamm elbow piece) [mm]
Dimensions, b (with Austroflamm elbow piece) [mm]
Dimensions, c (with Austroflamm elbow piece) [mm]
Dimensions, d (with Austroflamm elbow piece) [mm]
Flue pipe outlet, diameter [mm]
Outside air connection diameter [Ø mm]
Weight, basic appliance [kg]
Weight Xtra [kg]
Weight, HMS [kg]
Total weight inc. steel case (STM) [kg]
Total weight inc. ceramic case (KGM) [kg]
Total weight inc. soapstone case (SPM) [kg]
dP Radiation front [mm]
dS1 Distance left [mm]
dR Distance rear [mm]
dS2 Distance right [mm]
dB Distance bottom [mm]
Minimum distance from non-flammable materials [mm]
Output
Nominal heat efficiency [kW]
Minimum heat output [kW]
Maximum heat output [kW]
Minimum room heating capacity [m³]
Maximum room heating capacity [m³]
Energy efficiency class
5.3

Data for the chimney/flue dimensioning

Exhaust gas values for the multiple occupancy of the chimney (according to DIN 4705 Part 3) or rating
of the chimney (according to DIN 4705 Part 2)
Data for the chimney sweep
Exhaust gas mass flow [g/s]
Flue gas temperature [°C]
Minimum delivery pressure at nominal heat output [Pa]
at 0.8 times nominal heat output [Pa]
16
EN Operating manual Clou Compact Cook
1024
520
375
328
321
212
-
-
-
-
-
-
1601
887
656
105
130
125
112
-
37
122
-
-
1050
150
150
150
0
50
6.0
3.5
8.0
65
165
A
7.2
299
12
10
