Operating manual Ruby
5.2

General specifications

Technical data
Height [mm]
Width [mm]
Depth [mm]
Weight, basic appliance [kg]
Nominal heat efficiency [kW]
Partial load heat output [kW] (pellet)
Space heating capacity, at least (depending on the building insulation) [m³]
Maximum room-heating capacity (depending on the building insulation) [m³]
Efficiency [%]
CO [mg/Nm³] at 13% O2 wood operation/pellet operation
Flue gas temperature at nominal heat output [°C]
Partial output flue gas temperature [°C]
Flue gas mass flow [g/s]
Flue gas mass flow [g/s] for partial load
Minimum feed pressure at nominal heat output [Pa]
Minimum feed pressure for partial load [Pa]
Pellet hopper capacity [kg]
Pellet hopper capacity [l]
Fuel throughput, minimum [kg/h]
Fuel throughput, maximum [kg/h]
External air connection [Ø]
Flue pipe outlet, diameter [mm]
Power connection [V/Hz]
Temperature limits
Relative humidity
Fire safety – distance from combustible materials, ceiling [mm]
Minimum distance from non-flammable materials [mm]
Safety distances to combustible materials, front [mm]
Safety distances to combustible materials, side [mm]
Safety distances to combustible materials, back [mm]
EN 5 | Technical data
1120
690
442
226
8
2.3
114
305
90.0
11
158
75.9
4.7
2.9
12
10
25
38
0.6
1.87
60
80
230/50
0-40
non-condensing
-
50
1000
50
50
17
