Figure 5-1.
The assembled suction system
CUSA Excel Ultrasonic Surgical Aspirator System User's Guide
Above the green band,
2.
hold the suction tubing
with one hand; with the
other hand, stretch the
tubing into the suction
pinch valve.
Connect the green
3.
L-shaped connector on
the suction tube to the
PATIENT port on the
suction canister lid.
The following figure shows the suction system as it looks after successful
setup.
Connect the Suction Tubing
5-11
