1.9.4

Terminal block hand press tool

Material: ALUMINIUM
Dimensions in mm
XFP: 80C, 100C
80E, 100E, 150E
Ø25
Note:
40
120
1. All unspecified chamfers 0.5
2. All unspecified blends R2
ABS submersible sewage pump XFP 80C - 150E
80
16.55 Ø5.1 TYP
92°
26.5
20
20
18
Workshop Manual
Mark as "TOP"
C2.5 X 45
Ø61
Ø50
11 TYP
9
