Transition Piece And Upper Seal Extraction Tool - ABS XFP 80C-CB1 PE22/4-C-50 Workshop Manual

1.3
Transition piece and upper mechanical seal extraction tool
Material: MILD STEEL
Dimensions in mm
1 mm chamfers typical
XFP
80C, 100C
80E, 100E, 150E
* x 100 mm SHCS
Ø5.5
Sect 1 - 1
1
A B
Ø40 M12* 15
Ø50 M16* 20
ABS submersible sewage pump XFP 80C - 150E
A
B
C
D
E
F
1
G
C D E
Ø25 Ø42
Ø31 Ø60
Workshop Manual
110
100
30
F G
Ø62 Ø50
Ø80 Ø72
19
