- Page 1 ABS lifting station Piranhamat Installation and Operating Instructions www.absgroup.com...
-
Page 2: Table Of Contents
General maintenance hints ........................10 Steps to be taken should a fault occur ....................10 6.3.1 Piranhamat 100/120 does not work, motor makes a humming noise........... 11 6.3.2 Piranhamat 100/120 does not function and motor is silent..............12 6.3.3... -
Page 3: Application Areas
The Piranha-system shreds faecal effluent and allows it to be pumped through pipes of smaller diameter (from DN 25) or through flexible hose. It is important to note that the Piranhamat 100/120 is not a sanitary disposal unit, although it may shred particular sanitary items dropped accidentally into the WC. -
Page 4: Dimensions
������������ ���� ���������� ������������ ABS lifting station Piranhamat Horizontal discharge line length Figure 1 Maximum discharge line lengths for the optimum functioning of the unit. Allowance has been made for two 90° bends and ABS non-return valves. 1..1 D�m������� Dimensions in mm NOTE As certain European countries e.g. Germany specify a minimum inflow height of... -
Page 5: Nameplate
In the case of installations of this size and design of the Piranhamat 100/120, only a single WC, one wash-hand basin, one bidet and one shower tray may be connected. The direct or indirect connection of other effluent sources is not allowed. -
Page 6: Design Of The Piranhamat 100/120 Lifting Unit
ABS lifting station Piranhamat D���������� The lifting unit of the Piranhamat 100/120 series is supplied ready for installation and has been designed for the pumping of effluent containing faecal matter in accordance with DIN standards. The pump installed in a lifting unit is equipped with the ABS-Piranha-cutting system and has been designed to pump normal toilet domestic effluent. -
Page 7: F �H� P
The Piranhamat 100/120 (1) is designed for a direct toilet connection. The Piranhamat 100/120 unit is set-up directly behind the toilet. The sealing sleeve should be drawn up directly on to the toilet outlet pipe DN 100 (3). In order to comply with DIN standards the inflow lines from the wash-hand basin bidet and shower tray must be at least 180 mm above the container base and provision for inflow by gravity must exist in order that these inflow lines will remain clear. -
Page 8: Installation - Discharge Line
������������ - �����h����� ���� The discharge line can be connected to the Piranhamat 100/120 (1) from the left (3) or right (4) as required. The discharge port not used should be sealed off with cap (2) and securely tightened using the hose clamp provided. -
Page 9: Venting
������������ ���� ���������� ������������ ABS lifting station Piranhamat ABS lifting station Piranhamat 4.1. V������� The venting and aeration of the unit can take place into a room via the activated carbon filter with overflow prevention supplied as standard. A separate vent line (external diameter 25 mm) brought above roof level may be fitted. -
Page 10: C�Mm
6. G������ m���������� h���� ABS lifting units are reliable quality products each being subjected to careful final inspection. Lubricated-for- life ball bearings together with monitoring devices ensure optimum reliability, provided that the unit has been connected and operated in accordance with the operating instructions. -
Page 11: Piranhamat 100/120 Does Not Work, Motor Makes A Humming Noise
Screw back in plugscrew (9/8), refit cap (9/7), replace the float protection (9/6) and refit the tank cover (9/1). The latches (9/2) must correctly lock into position. ATTENTION The unit should only be used or tested with the top cover correctly in place. Carry out functional test. If the Piranhamat 100/120 still does not work, withdraw plug and call ABS Service. -
Page 12: Piranhamat 100/120 Does Not Function And Motor Is Silent
After this waiting period push back in the plug. Water sources should not be used in this period. If after this waiting period the Piranhamat 100/120 does not function correctly, then withdraw the plug and call the ABS service. NOTE In the case of any queries, it is essential that the pump type and part number are given. -
Page 13: Removal Of The Piranhamat 100/120
������������ ���� ���������� ������������ ABS lifting station Piranhamat ABS lifting station Piranhamat 6.3.4 R�m�v�� �f �h� P����h�m�� 100/10 Figure 10. Emptying the Tank Before dismantling the discharge and inflow lines, it is possible to empty the tank by driving the pump by means of an electric drill. - Page 14 ������������ ���� ���������� ������������ ABS lifting station Piranhamat...
- Page 15 NO: Som dekkes av denne erklæringen, er i samsvar med følgende standar- SK: Na ktoré sa vz ahuje toto vyhlásenie, zodpovedajú nasledujúcim der eller andre normative dokumenter štandardom a iným záväzným dokumentom. D�N EN 1050-1, EN 60335, EN 13463, EN �S� 1100-1 & EN �S� 1100- 03-01-2006 Sean Roche ABS P���������� W�xf���� L���. ABS reserves the right to alter specifications due to technical developments...
- Page 16 ABS Production Wexford Ltd., Clonard Road, Wexford, Ireland Tel. +353 53 91 63 200 Fax +353 53 91 42335. www.absgroup.com...
