ABS submersible sewage pump XFP 80C - 150E
1.9.1

Motor housing support fixture

Material: MILD STEEL
Dimensions in mm
XFP: 80C, 100C
150
170
68
58
Ø178
Ø250
190
XFP: 80E, 100E, 150E
200
226
70
84
Sect A-A
Raw material dia. 300
A
A
Ø231
R150
