0 Workshop Manual
ABS submersible sewage pump XFP 80C - 150E
1.4

Transition piece hand press tool

Material: NYLON
Dimensions in mm
Ø60
Ø48
XFP: 80C, 100C
1 mm chamfers typical
170
130
Ø80
30
18
Ø64
Ø84
XFP: 80E, 100E, 150E
170
130
