Stator Inserting Tool - ABS XFP 80C-CB1 PE22/4-C-50 Workshop Manual

Submersible sewage pump
Hide thumbs
Table of Contents

Advertisement

8 Workshop Manual
ABS submersible sewage pump XFP 80C - 150E
1.9.3

Stator inserting tool

Material: MILD STEEL
Dimensions in mm
XFP
80C, 100C
80E, 100E, 150E
6
C
A
B
Ø132
144
Ø180
156
A
D
E
F
C
D
50
Ø144.9
60
Ø192
15
B
E
F
Ø152
Ø220
Ø200
Ø265
