12 | English
of a wall or ceiling joint without changing: his position.
1. Turn vacuum cleaner switch ON.
2. CAUTION: Wear a respirator approved for "Dust
and Mist".
3. Turn Drywall Sander switch ON.
4. Position drywall sander lightly against work sur-
face (apply just enough pressure to align the sand-
ing head with the work surface).
5. Apply additional pressure to engage the abrasive
pad to the work surface: while moving the Sander
in an overlapping pattern to smooth the drywall
compound down to a "featheredge'.
Apply ONLY enough pressure to keep the abrasive pad
flat against the work. Excessive pressure can cause unac-
ceptable swirl marks and unevenness in the work surface.
Keep the sander in constant motion while abrasive pad is
in contact with the work surface. Use a steady, sweeping
motion. Stopping the Sander (on the work), or moving
the Sander erratically can cause unacceptable swirl marks
and unevenness in the work surface.
NOTE
Do not allow rotating abrasive pad (Fig.7) to contact
sharp protrusions. Contact with protruding objects (nails,
screws, electrical boxes, etc.), can severely damage the
abrasive pad.
ABRASIVE PAD REPLACEMENT
CAUTION
Disconnect Sander from Power Supply.
Grasp the abrasive pad and the sander housing (clamping
the pad to the housing), to prevent pad rotation.
1. Rotate the pad retaining nut, counterclockwise
and remove.
2. Lift off the large metal washer, and the abrasive
pad.
3. NOTE: When the abrasive pad, is lifted off the
Sander: the abrasive back-up disc is exposed.
Please note that this back-up disc is also covered
with an abrasive material. This abrasive material
is ONLY used to prevent "slippage" between the
back-up disc and the foam backed abrasive pad, it
is NOT suitable for use as a sanding abrasive. Do
not use the sander without a proper abrasive pad
installed (to prevent severe damage to the work).
4. Position new abrasive pad to the back-up disc,
making sure that the center hole in the abrasive
disc is centered on the hub of the back-up disc.
5. Position the large metal washer the retaining nut
to the Sander.
6. Rotate the retaining nut clockwise to hand tight-
en (while holding the abrasive pad).
ASSEMBLE FOR LONGER HANDLE (Fig. 6)
Please refer to figure 6.
Insert one tube into the other. Screw.
The extension has been installed.
MAINTENANCE
Keep tools clean, clean up debris and dust.
Often add in lubricating oil and grease (reducer, bearing)
to keep the tool on flexible operation.
ENVIRONMENTAL PROTECTION
This product must not be disposed together with
domestic waste in compliance with relative legisla-
tion concerning waste of electrical and electronic
equipment where applicable. Recycle raw materials
instead of disposing as waste. Product, accessories
and packaging should be sorted for environment
friendly recycling. By properly disposing this prod-
uct, you are also contributing to the effective use of
natural resources.
You can obtain information on collection points for
waste equipment from your municipal administra-
tion, public waste disposal authority, an authorized
body for the disposal of waste electrical and elec-
tronic equipment or your waste disposal company.
WARRANTY
This product is warranted in accordance with the le-
gal / country specific regulations, effective from the
date of purchase by the first user. Consult your au-
thorized dealer for disassembly and service, not cov-
ered in this manual. In case of a claim, please send
the product, completely assembled, to your dealer
or the official service center.
Warranty covers the cost of repairing the product
and any required replacement of parts that are de-
fective in terms of material or manufacturing and
does not apply:
Where repairs have been made or attempted by
f
people other than the official or an authorized repair
center.
Where modifications or falsifications of the product
f
have been made.
Where non-genuine or non-recommended parts,
f
consumables or accessories have been installed.
In case of overuse, unorthodox use or any use not in
f
accordance with the user manual.
In case of poor maintenance or exposure to harmful
f
environmental factors.
Where repairs are needed due to normal wear or to
f
consumables, accessories, power cables, supporting
batteries and other related items.
For minor deviations from the specifications that
f
are not necessary for the proper operation of the
product.
For damages that are the result of factors other than
f
the product, such as natural disasters, theft, wear
and tear during transport, accidental damage etc.
Where the product is used as a rental item.
f
Where the product is an exhibition item, sample or
f
has been supplied free of charge.
