Unlock Scanner; Connect Scanner - Microtek Spector-AF10 Start Here Manual

3.

Unlock Scanner

A. Remove the yellow sticker "Unlock
Scanner" from your scanner.
B. With the scanner power off, tilt the
back right corner of the scanner to see
the locking switch at the bottom.
C. Push the locking switch to the position
as indicated in the graphic, with the
icon on the lock showing as "Unlocked".
NOTE: To lock the scanner (for shipping and other reasons), tilt the scanner and look for the locking
switch on the left corner at the back, then push the locking switch to the "Locked" position. DO
NOT turn the scanner upside down when attempting to lock the unit.
4.

Connect Scanner

To the power adapter
A. Connect one end of the power adapter to the back of the scanner.
B. Plug the other end of the power adapter into a power source.
To the Hi-Speed USB cable
C. Connect one end of
the USB cable to
your computer.
D. Connect the other
end of the USB cable
to the scanner's USB
port.
E. Hold down the Power
button ( ) on the
scanner's button panel to
turn on the scanner. The front
orange LED
indicator will light up.
Once the scanner is detected by your system,
the green LED indicator will also light up,
indicating that your scanner is now ready for use.
Unlocked
A
B
(Left: Green/Right: Orange))
2
Locked
D
WEB
PDF
OCR
E-MAIL
COPY
SCAN
Power button
POWER
LED indicators
C
