Unlock Scanner

A. Remove the yellow "Unlock
your scanner.
B. With the scanner power off, tilt the front right
corner of the scanner to see the locking switch at
the bottom.
C. Push the locking switch to the position as indicated
in the graph, with the icon on the lock showing as
"Unlocked".
NOTE: To lock the scanner (for shipping and other reasons), tilt the scanner and look for the locking switch
on the right corner at the front, then push the locking switch to the "Locked" position. DO NOT turn the
scanner upside down when attempting to lock the unit.

Connect Scanner

To the power adapter
A. Connect the power adapter to the back of the scanner.
B. Plug one end of the power cord into the power adapter, and plug the other end of the
power cord into a wall outlet or other power source.
To the Hi-Speed USB cable
C. Connect one end of the cable to your computer.
D. Connect the other end of the cable to the scanner's USB port.
E. Press and hold the Power button
( ) until the orange LED lights on.
Once the scanner is
powered on, the
green LED will be
lighted up, and the
7-segment LED
display (SSD) will
also be activated as
well.
The system will
detect the scanner
automatically.
Scanner" sticker from
Power button
located at the
front of the
E
scanner.
C
2
Locked Unlocked
A
D
B
