MAIN MACHINE COMPONENTS

6
5
4
3
2
1
1 Scrubbing brush head
2 Front headlights
3 Solution tank
4 Solution tank inlet cap
5 Recovery tank
6 Recovery tank cover
7 Control handlebar
8 recovery tank drainage tube
12
13
14
15
12 Solution tank capacity level hose
13 Detergent solution adjustment tap
14 Adjustment screw for squeegee tilt
Knob for adjusting the height of the
15
squeegee unit
7
8
9
10
11
9
10
11
20
19
18
17
16
16
17
18
19
20
- 10 -
Parking brake
Front wheels
Rear wheels
Solution tank filter
Brush head body control pedal
LED lights on-board charger
(optional)
On-board charger power socket
(optional)
Squeegee body control lever
