Fimap EMX Use And Maintenance Manual page 71

WARNING: the following operations must be carried out by qualified personnel. Incorrect operations could
result in machine malfunctions.
6. Check that the connector (5) in the wiring of the machine's electrical system is connected to the connector (6)
in the power cable coming from the battery box, otherwise connect it (Fig.4).
7. Grip the handle (2) and turn the recovery tank (3) to its working position.
8. Insert the key (1) into the slot on the right side of the control handlebar.
9. Turn on the machine and turn the key (1) a quarter turn clockwise (Fig.5).
10. Move to the working position (in contact with the floor), press the pedal (7) all the way down, move it to the
right and release it (Fig.6).
6
5
4
11. Bring the squeegee body into the working position (in contact with the floor), turn the lever (11) downwards
(Fig.8).
12. Set the parking brake to the rest position, turn the lever (12) anti-clockwise (Fig.9).
13. The machine is now operating with the ECO MODE program active and in SCRUBBER working mode.
8
7
14. When you push the dead man's lever (15) (Fig.9), the machine will begin to operate.
N.B.: as soon as the lever (15) is pressed, the brush motor; the solenoid valve, and the detergent solution
pump only begin functioning once the brush head is in its working position.
N.B.: the suction motors are only activated once the squeegee is in its working position.
15. The machine will now begin operating at maximum efficiency until the detergent solution is finished or the
battery box runs flat.
N.B.: during the first few meters of work, check that the amount of solution is sufficient to wet the floor, if not,
adjust the flow of the cleaning solution.
N.B.: during the first few meters of work, check that the squeegee dries the floor properly. If not, adjust it.
See "ADJUSTING THE SQUEEGEE RUBBER BLADES" on page
1
5
9
8
- 71 -
7
6
115.
