Operating Guide | iC7-Marine PROFINET

Troubleshooting

6

Diagnostics

6.1
The iC7 series supports diagnostic event messaging for control systems by using faults and warnings. The faults and warnings are
enabled by default. Whenever one occurs, it is indicated on the display of a control system. If diagnosis interrupt is used by the control
system, it is possible to read out the fault or warning event within the PLC program and to react accordingly.
Table 21: Diagnostics Parameters
Menu index Parameter
name
10.3.2.3.1 Diagnostics
Fault
10.3.2.3.2 Diagnostics
Warning

PROFINET Report

6.2
The PROFINET report is available in MyDrive® Insight, in parameter 10.3.2.1.1. The report shows the current status of:
Connections
l
Configuration
l
Mapped signals and their values
l
36
| Danfoss Drives Oy © 2024.04
Parameter Value
number
7081
• Enabled (default)
• Disabled
7083 • Enabled (default)
• Disabled
Description
Enables diagnostic fault.
When disabled, the device does not send any
PROFINET diagnosis message with severity
Fault when a fault is present on the device.
Enables diagnostic warning.
When disabled, the device does not send
any PROFINET diagnosis message with sever-
ity Maintenance requiredwhen a warning is
present on the device.
