Operating Guide | iC7-Marine PROFINET

Product Overview

2

PROFINET Features and Technical Data

2.1
Fieldbus options for iC7 are integrated in the control board. Fieldbuses are enabled on communication interfaces X1 and X2 only.
Modbus TCP is offered as standard, and other protocols such as PROFINET RT can be selected in the configurator when ordering a drive
or power converter, or alternatively, they can be activated later by a proof-of-purchase token.
Table 3: PROFINET Model Codes
Model code
+BAPR
PROFINET is the Ethernet-based automation standard of PROFIBUS and PROFINET International (PI) for the implementation of an
integrated and consistent automation solution based on Industrial Ethernet. PROFINET supports the integration of distributed field
devices and time-critical applications in switched Ethernet networks. It also supports the integration of component-based distributed
automation systems for vertical and horizontal integration of networks.
Table 4: PROFINET Features
Feature
Cyclic response
Diagnostics
Connection
System integration
PROFIenergy

Communication Profiles and Objects

2.2
The iC7 series complies with PROFINET and PROFIdrive standards, mandatory PNU objects, PROFINET Extended Diagnostics, and a range
of vendor-specific profiles for product-specific applications.
Communication profiles are selected in parameter Fieldbus Profile (parameter number 1301).
10
| Danfoss Drives Oy © 2024.04
Description
PROFINET RT OS7PR
Technical data
1 ms update cycle
PROFINET RT Conformance Class B (CC-B)
Data consistency with submodule
PROFINET Extended Diagnostics
PROFINET Diagnostics (ALARM CR)
MRP (Media Redundancy Protocol)
LLDP/SNMP
Netload Class III, Advanced robustness against net load
IPv4
Addressing mode: DCP, STATIC, DHCP/BOOTP
Supported GSDML versions:
• GSDML version 2.42: current version
• GSDML version 2.35: compatible with legacy systems
• GSDML version 2.31: compatible with legacy systems
Version 1.3
