Table 5: Communication Profiles and Supported Applications for iC7-Marine
Profile
PROFIdrive Application Class 1
PROFIenergy version 1.3
PROFIdrive standard PNUs

iC Speed Profile

iC Active Front End Profile
iC Speed Profile
2.3

Overview

2.3.1
The iC speed profile is used with the iC7 series motor applications. The iC speed profile differs from the PROFIdrive profile, because
it does not have a State Machine. It is only controlled by the actual state 1/0 of the control bits, not the sequence in which they are
manipulated.

Control Word (CTW)

2.3.2
Table 6: iC Speed Profile Control Word Bits
Bit number Name
0+1 Preset reference selector
2 Reserved
3 No coast/Coast
4 No quick stop/Quick Stop
5 No hold/Hold output frequency
6 Start/No start
7 Fault acknowledge
Danfoss Drives Oy © 2024.04
Propulsion & Machinery
X
X
X
X
–
Description
00: Preset reference 1
01: Preset reference 2
10: Preset reference 3
11: Preset reference 4
Reserved for future use.
Any control words sent to the device should keep this bit at 0 to ensure
compatibility with future extensions of the control word.
1: No function.
0: Causes the drive to immediately coast the motor.
1: No function.
0: Quick stops the drive and ramps down the motor speed to stop as de-
fined with the quick stop ramp parameter.
1: No function.
0: Hold the present output frequency (in Hz).
1: If the other starting conditions are fulfilled, this selection allows the
drive to start the motor.
0: Stops the drive and ramps down the motor speed as defined with the
ramp down parameter.
0 ⇒ 1: Acknowledge faults.
Acknowledge is edge-triggered, when the logic is changed from 0 to 1.
Faults can only be acknowledged is the triggering condition has been re-
moved and any required acknowledgment has been done.
0: No function.
Active Front End
–
X
X
–
X
