Operating Guide | iC7-Marine PROFINET
Table 6: iC Speed Profile Control Word Bits (continued)
Bit number
Name
8
Jog/No jog
9
Ramp select
10
Data valid
11
Reserved
12
User defined
13
User defined
14
User defined
15
User defined
Status Word (STW)
2.3.3
Table 7: iC Speed Profile Status Word Bits
Bit number
Name
0
Control ready/Control not ready
1
Drive ready/Drive not ready
2
Coasting/No coast
3
Fault/No fault
4
Reserved
5
Reserved
6
Reserved
7
Warning/No warning
12
| Danfoss Drives Oy © 2024.04
Description
1: Sets the output frequency to the jog speed defined with the jog speed
parameter.
0: No function.
1: Ramp 2 is active.
0: Ramp 1 is active.
1: Use process data (control by PLC).
0: Ignore the current process data. This is linked to the submodule where
the CTW is present. If signals are to be covered, the CTW/STW profile (for
example, the iC Speed Profile) must be part of the signals list.
Use the previously processed data when the data valid bit was true (no
control by PLC).
Reserved for future use.
These bits are reserved for application-specific advanced control. For
more information, refer to the Parameter Descriptions chapter in the ap-
plication guide.
Description
1: The device controls are ready and react to process data.
0: The device controls are not ready and do not react to process data.
1: The drive is ready for operation.
0: The drive is not ready for operation. This does not involve faults and
warnings as they are indicated in their respective bits elsewhere.
1: There are no active coast signals, and the motor can start when a start
signal is given.
0: The drive has an active coast signal and has released the motor.
1: A fault has occurred, and an acknowledge signal is required to re-es-
tablish operation.
0: There are no faults.
Reserved
Reserved
Reserved
1: A warning has occurred.
0: There are no warnings.
AQ481922043454en-000101 / 172K4282A
