TROUBLESHOOTING

System is not Confirm the utility power is on (authorized personnel only).
Operating
Check the circuit breaker box for tripped circuits (authorized personnel only).
Case Lights Not Check that light switch is in the ON position.
Working
•
If case is not hard-wired, check that power cord is properly connected to wall outlet.
Check that ALL of the light plugs are properly connected to the LED light.
•
•
Power may not be reaching the case.
•
If case light still do not come on, it may need to be replaced.
•
•
--- "Barrel-Shaped" LED Plug & Light Fixture ---
LED Light
LED's Barrel
Shaped Insert
See CASE STARTUP / LED LIGHT REMOVAL & REPLACEMENT / LED
DRIVER BOX section in manual for switch location (regardless of case design).
Plug must be inserted ALL THE WAY into the LED light orifice (with no gap).
See illustrations below.
Contact store management to have trained service provider perform
troubleshooting.
Contact Structural Concepts' Technical Service Department for replacement
light (see TECHNICAL SERVICE section of this manual for contact
information).
To replace, disconnect plug from existing LED light. Disconnect LED light from
its brackets. Replace with new LED light. Insert plug ALL THE WAY into LED
light orifice.
Plug
10
Gap
No Gap
