SELF-SERVICE MODE VS. SERVICE MODE VS. RANDOM SHELVING POSITIONING

1. Self-Service Mode Shelving Position
•
Shelves may be positioned in the "up" position to
merchandise as a self-service case.
• Number of open slots above, between and below
shelving remains the same as unit in service mode.
•
See illustration #1 below.
2. Service Mode Shelving Position
• Shelves may be positioned in the "down"
1. Merchandiser In Self-Service Mode
Shelving Brackets
Set At First Notch
2. Merchandiser In Service Mode
Shelving Brackets
Set At Third Notch
position to merchandise as a service case.
•
Number of open slots above, between and below
shelving remains the same as unit in self-service
mode.
• See illustration #2 below.
3. Random Mode Shelving Position
•
Shelves may be adjusted to second notch at will.
• Shelves may also be raised or lowered to desired
slot along uprights.
