CHATPER 4. CLEANING

4.1 Cleaning with a Cleaning Card

Use the Cleaning Card provided to clean the Card Transport Roller if cards do not feed
smoothly.
We recommend cleaning the rollers after printing 1,000 cards.
Cleaning Cards can only be used once and cannot be reused. Use a new Cleaning Card
with the adhesive side down every time you clean the rollers. Do not touch the platen
with hands.
① Power on the printer while holding Right Key;
② When finding the "Cleaning" option, press Right Key. The second line of the screen shows "cooling
***℃". "***℃" indicates current temperature of the heating roller;
③ Wait until the figure drops to 70 ℃. When [Remove Film Cartridge] is displayed, open the
Front Cover, and remove the Retransfer Film Cartridge;
④ Close the Front Cover, [Remove Cards] is displayed. (If there's no card in the slot, just ignore
this step) ;
⑤ After removing the cards, [Set Cleaning Card] is displayed, put the cleaning Card in the card
Feeding Slot;
⑥ When [SET : Start] is displayed, press the Right Key to start cleaning;
⑦ After cleaning, [Over, Put Film Again] is displayed, open the Front cover and put in the film,
then close the cover;
⑧ After closing the cover, [Restart Printer ] is displayed;
⑨ Restart the printer, the printer will be initialized. After initialization, user can continue
printing.
