CHATPER 4 CLEANING

4.1 Cleaning with a Cleaning Card

Use the Cleaning Card provided to clean the Card Transport Roller if cards do not feed
smoothly.
We recommend cleaning the rollers after printing 1,000 cards.
Cleaning Cards can only be used once and cannot be reused. Use a new
Cleaning Card with the adhesive side down every time you clean the
rollers. Do not touch the platen with hands.
Switch from Normal Mode to User Mode. Press the 【▲】or【▼】to find the [Cleaning].
①
②
"No", press the SET Key and press【▼】. When the second line display "Yes", press the SET Key. At
this moment, the screen will display "cooling,***℃"， "cooling,***℃" is the current temperature
of feeding roller.
When [Cool Down ---] is displayed, wait until the figure drops to 70 ℃. When [Remove Film]
③
is displayed, open the Front Cover, and remove the Retransfer Film.
4 C lose the Front Cover, [Remove Cards] is displayed. (If there's no card in the slot, just ignore
○
E A
this step)
After removing the cards, [Set Cleaning Card] is displayed, put the cleaning Card in the card
⑤
Feeding Slot.
When [SET : Start] is displayed, press the SET Key to start cleaning.
⑥
After cleaning, [Finish, reset the film] is displayed, open the Front cover and put in the film,
⑦
then close the cover.
After closing the cover, [Press the Menu button to exit the Cleaning mode ]is display.
⑧
○
9 E xit the User Mode, [wait for pressing Set Key] is displayed. When user presses the Set Key,
A E A
the printer will be initialized. After initialization, user can continue printing.
