Dascom DC-8600 User Guide V1.0
To reduce the chance of card jamming:
① See Section 2.1.3 to set the proper card thickness dial
② Use cards with thickness specified in the specifications.
③ Check that cards are not bent.
④ Before putting the cards to the card cassette, shuffle the cards by holding the outside edges
to prevent sticking cards.
To take out jammed card
When card jam occurs, the LCD display prompts "Printer Card Jam" and the print job stops.
Do not turn off the power as the uncompleted print job will be lost.
① Open the top cover and front cover.
② Take out the card cassette.
③ If the last card is completely fed into the printer, pull it out slowly by hand.
④ Replace jammed card back to the card cassette.
⑤ Close the card feed cover and the printer covers.
⑥ Press the Right Key. The error message disappears from the LCD display and the printer
restarts.
To take out jammed card in the thermal retransfer unit
When card jam occurs, the LCD display prompts "Feeder Card Jam" and the print job stops.
Do not turn off the printer as the uncompleted print job will be lost.
① Open the top cover。
② Take out the card cassette.
③ Rotate the feeding knob in counter-clockwise direction. Take out the jammed card from
the cleaning section.
④ Replace jammed card back to the card cassette.
⑤ Close the card feed cover and the printer covers.
⑥ Press the Right Key. The error message disappears from the LCD display and the printer
restarts.
To take out card jammed in the reverse section
① Open the top cover and front cover.
② Take out the card cassette.
③ Release the lock and lift it up as shown in the diagram.
④ Take out the cleaning roller and cleaning cartridge.
⑤ Rotate the reverse knob. Turn the feeding knob back and forth. The jammed card may
come out from the left or right card slot.
⑥ Replace jammed card back to the card cassette.
⑦ Make sure the retransfer film is not shifted by this process. Put flattening part, cleaning
roller/cartridge, and card cassette back in place. Close the printer cover.
⑧ Press the Right Key. The error message disappears from the LCD display and the printer
