1.5 HYDRAULIC CIRCUIT (fig. 2)
1
M
R
KEY
1 Cascade supply probe (SMC)
2 Low Loss Header
3 Loss Header Connection Kit
5 Condensate drain trap
6 Gas valve
7 -------
8 Fan
9 Heating supply probe (SM)
10 Safety thermostat 100°C
11 Exhaust probe (SF)
12 Primary exchanger
14 Heating return probe (SR)
15 Water pressure transducer
16 Air release vent
17 Check valve
18 Pump high efficiency
1.6 AVAILABLE PREVALENCE TO THE SYSTEM, COLLECTORS DELIVERY AND SUPPLY FITTINGS
"MURELLE EQUIPE 220-550 ErP" (fig. 3)
800
700
600
500
400
300
200
100
8
11
9
10
8
5
30
S3
3
25
2
G
3
26
0
5
12
16
14
15
6
18
24
27
17
22
19 -------
20 -------
21 -------
22 3-way drain tap
23 -------
24 Single module drain
25 Gas tap
26 8 litre expansion tank (supplied with connection kit)
27 Safety valve 5 bar
29 -------
30 -------
FIXTURES
M C.H. flow
R C.H. return
G Gas
S3 Condensation drain
10 15
20
CAPACITY (m 3 /h)
3
PORTATA (m /h)
Fig. 2
Fig. 3
