1.2.2 MURELLE EQUIPE 440-550 ErP (fig. 1/b)
MURELLE EQUIPE 440-550 UK
M
R
500 590
FIXTURES
M C.H. flow (Flange PN6-DN100)
R C.H. return (Flange PN6-DN100)
G Gas (Flange PN6-DN50)
S3 Condensation drain ø 40
1.2.3 MURELLE EQUIPE 660 ErP (fig. 1/c)
M
R
Kit - 8101533
500 590
FIXTURES
M C.H. flow (Flange PN6-DN100)
R C.H. return (Flange PN6-DN100)
G Gas (Flange PN6-DN50)
S3 Condensation drain ø 40
L
ø D
L
DIMENSIONS
Murelle Equipe
L mm
H mm
D mm
3314
131
374
620
155
S3
G
440 ErP 550 ErP
2208 2760
2360 2394
200 200
ø 250
S3
G
131
374
620
Fig. 1/b
154
131
374
620
Fig. 1/c
