2
Mount the collector supporting brackets, fastening them to the frame using
the washers and M10 nuts.
The position where to place the washer and bracket blocking nut is indi-
cated by two arrows in correspondence with the frame studs to be used.
Mount the supports of the condensate drain collector, fastening them to
the supporting brackets, using the M5 screws.
18
