1.3 TECHNICAL SPECIFICATIONS MURELLE EQUIPE 220-550 ErP
MURELLE EQUIPE
Heat output
Nominal (80-60°C) (Pn max)
Nominal (50-30°C) (Pn max)
Minimum (80-60°C) (Pn min)
Minimum (50-30°C) (Pn min)
Heat input (*)
Nominal (Qn max - Qnw max)
Minimum (Qn min - Qnw min)
Min/max operating yield (80-60°C)
Min/max operating yield (50-30°C)
Operating yield at 30% (40-30°C)
Losses after shutdown to 50°C (EN 15502)
MURELLE HE 110 R ErP generators
Feeding tension
Absorbed power consumption (Qn max)
Absorbed power consumption (Qn min)
Absorbed power consumption modulating pump
Electrical protection grade
Energy efficiency
Seasonal energy efficiency class of the heating system
Seasonal energy efficiency of the heating system
Sound power of the heating system
Single module temperature regulation
Water content modules
Max operating pressure (PMS)
Max operating temperature (T max)
Exhaust temperature at max flow rate (80-60°C)
Exhaust temperature at min flow rate (80-60°C)
Exhaust temperature at max flow rate (50-30°C)
Exhaust temperature at min flow rate (50-30°C)
Smokes flow min/max
CO at min/max flow rate (G20)
2
CO at min/max flow rate (G31)
2
NOx measured (EN 15502-1:2015)
Max. output pressure fumes manifold
Max. pressure independent fumes
PIN number
Category
Type
NOx emission class (EN 15502-1:2015)
Nozzle
Number
Nozzle diameter (G20)
Nozzle diameter (G31)
Gas consumption at nominal/minimum output
Nominal (G20)
Minimum (G20)
Nominal (G31)
Minimum (G31)
Supply pressure (G20/G31)
(*) Heat input of the heating system measured using lower heating value (LHV)
6
220 ErP
kW 212,6 (2 x 106,3)
kW 229.2 (6 x 114.6)
kW 21.1
kW 23.6
kW 216.0 (2 x 108.0)
kW 21.6
% 97.7 / 98,4
% 109.1/106.1
% 108.1
W 548
n° 2
V-Hz 230-50
W 536 (2 x 268)
W 134
W 280 (2 x 140)
IPX4D
A
% 93
dB (A) ---
°C 20/80
l 36.3
bar (kPa) 5 (490)
°C 85
°C 86.2
°C 74.6
°C 61.6
°C 49.2
g/s 10.28/103.34
% 9.0/9.0
% 10.2/10.2
mg/kWh 22
Pa 375
Pa 428
n° 1
ø 17.2
ø 9.8
m 3 /h 22.84 (2 x 11.42)
m /h 2.28
3
kg/h 16.76 (2 x 8.38)
kg/h 1.68
mbar (kPa) 20/37 (1.96/3.63)
330 ErP 440 ErP
318,9 (3 x 106,3) 425,2 (4 x 106,3)
343.8 (3 x 114.6) 458.4 (4 x 114.6)
21.1 21.1
23.6 23.6
324.0 (3 x 108.0) 432.0 (4 x 108.0)
21.6 21.6
97.7 / 98,4 97.7 / 98,4
109.1/106.1 109.1/106.1
108.1 108.1
821 1095
3
230-50 230-50
804 (3 x 268) 1072 (4 x 268)
138 142
420 (3 x 140) 560 (4 x 140)
IPX4D IPX4D
A
93 93
--- ---
20/80 20/80
55.9 72.6
5 (490) 5 (490)
85 85
86.2 86.2
74.6 74.6
61.6 61.6
49.2 49.2
10.28/155.00 10.28/206.67
9.0/9.0 9.0/9.0
10.2/10.2 10.2/10.2
22 22
375 375
428 428
1312CM5614
II2H3P
B23-B53-B23P-B53P-C13-C33-C43-C53-C83
6 (‹ 56 mg/kWh)
1
17.2 17.2
9.8 9.8
34.26 (3 x 11.42) 45.68 (4 x 11.42)
2.28 2.28
25.14 (3 x 8.38) 33.52 (4 x 8.38)
1.68 1.68
20/37 (1.96/3.63) 20/37 (1.96/3.63)
550 ErP
531,5 (5 x 106,3)
573.0 (2 x 114.6)
21.1
23.6
540.0 (5 x 108.0)
21.6
97.7 / 98,4
109.1/106.1
108.1
1369
4 5
230-50
1340 (5 x 268)
146
700 (5 x 140)
IPX4D
A A
93
---
20/80
92.2
5 (490)
85
86.2
74.6
61.6
49.2
10.28/258.34
9.0/9.0
10.2/10.2
22
375
428
1 1
17.2
9.8
57.10 (5 x 11.42)
2.28
41.90 (5 x 8.38)
1.68
20/37 (1.96/3.63)
