1.13
KIT CODE 8101533 "MURELLE EQUIPE 440-550-660 ErP"
(to be requested separately) (fig. 7)
– N. 1 kit with collector delivery tube, code
6291969,
collector
6291971, 8 litres expansion vessel, code
6245108, expansion vessel connection tube,
code 6227661, reduced nipple 1" - 3/4", code
2040252, gaskets, nuts and M16 fixing screws
1.14
CODE 8101552 "MURELLE EQUIPE 220-330 ErP" (to be requested separately) (fig. 8)
– N. 1 hydraulic compressor with gaskets, nuts
and M16 fixing screws
1.15
CODE 8101553 "MURELLE EQUIPE 440-550-660 ErP" (to be requested separately) (fig. 9)
– N. 1 hydraulic compressor with gaskets, nuts
and M16 fixing screws
16
return
tube,
code
C
C
Fig. 7
Fig. 8
Fig. 9
