GIRBAU HS-6028 Installation Instructions Manual
  1. Manuals
  2. Brands
  3. GIRBAU Manuals
  4. Washer
  5. HS-6028
  6. Installation instructions manual
GIRBAU HS-6028 Installation Instructions Manual

GIRBAU HS-6028 Installation Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Installation
Instruction
Manual for washers
HS-6013/HS-6017/HS-6023/
HS-6024/HS-6028/HS-6032
EH030/EH040/EH055/
EH060/EH070/EH080
GIRBAU, SA
Crta de Manlleu, km. 1
08500 VIC (Barcelona) • SPAIN
National sales:
T.(+ 34) 902 300 359
comercial@girbau.es
International sales:
T.(+ 34) 938 862 219
sales@girbau.es
Service:
T.(+ 34) 902 300 357
sat@girbau.es
www.girbau.es
EN
For USA and CANADA:
Installation
CONTINENTAL GIRBAU Inc.
2500 State Road 44
WI 54904 Oshkosh • USA
Tel. 1(920) 231-8222
info@continentalgirbau.com
www.continentalgirbau.com
Cod.nº 429043
Rev. No. 21/0519

Advertisement

Table of Contents
loading

Related Manuals for GIRBAU HS-6028

Summary of Contents for GIRBAU HS-6028

  • Page 1 T.(+ 34) 938 862 219 sales@girbau.es Service: T.(+ 34) 902 300 357 sat@girbau.es www.girbau.es For USA and CANADA: Installation CONTINENTAL GIRBAU Inc. 2500 State Road 44 WI 54904 Oshkosh • USA Tel. 1(920) 231-8222 info@continentalgirbau.com www.continentalgirbau.com Cod.nº 429043 Rev. No. 21/0519...
  • Page 2 Model From serial # HS-6013 2,110,001 EH030 1,460,001 HS-6017 2,120,001 EH040 1,470,001 HS-6023 2,140,001 EH055 1,490,001 HS-6024 2,390,177 EH060 2,400,387 HS-6028 2,520,000 EH070 2,520,000 HS-6032 2,450,001 EH080 2,460,001 Cod.nº 429043 Rev. No. 21/0519...

  • Page 3: Table Of Contents

    2. RECEIPT, TRANSPORT AND LOCATION ....................28 2.1. Receipt ..............................28 2.2. Transport of the machine ........................28 2.3. Safety door unlock (HS-6023, HS-6024, HS-6028, HS-6032, EH055, EH060, EH070, EH080 models only) ................................29 2.4. Washer location Conditions........................29 2.5. Installing more than one washer ......................31 2.6.
  • Page 4 1. The actions described in these instructions are strictly reserved for contractually AUTHORISED TECHNICAL SERVICES (ATS) and personnel who have successfully completed training by Girbau 2. The company responsible for the Authorised Technical Service accepts full liability for the work done and any possible consequences that may derive from it.
  • Page 5 Safety instructions Before beginning any procedure on machines equipped with an inverter or equipment with capacitative loads, wait for at least five minutes (10 minutes on equipment with a power rating greater than 25 kW) after the electrical disconnection, to eliminate risk of residual voltage. Close and mechanically lock the manual WATER, GAS, STEAM, THERMAL OIL, COMPRESSED AIR, etc.

  • Page 6: Safety Instructions

    Safety instructions SYMBOLS USED IN MACHINE LABELLING Electrical risk High temperature risk Protective guard for elements carrying Handle with caution. an electric current. Use adequate protection. Risk of inhaling harmful or irritant Mechanical risk vapours Protective guard for moving parts. Keep the doors/covers closed.

  • Page 7: Technical Specifications

    • Shipping restraints ......open end wrench 11/16 inch. (17mm) Shipping restraints ......tubular wrench 11/16 inch. (17mm) • HS-6023; HS-6024; HS-6028; HS-6032; EH055; EH060; EH070; EH080 Shipping restraints ......open end wrench ¾ inch. (19mm) • • Shipping restraints ......offset ring wrench 3/4 inch. (19 mm) Shipping restraints ......

  • Page 8: Declaration Of Conformity

    Technical specifications 1.3. Declaration of conformity HS-6013 model EU DECLARATION OF CONFORMITY Manufacturer: GIRBAU S.A. Address: Ctra. de Manlleu, km 1, 08500 Vic, Barcelona, SPAIN Identification of the machine Generic denomination: Function: Type: Washer extractor Washing in a water bath and extracting textiles Front loading Lavadora –...
  • Page 9 Technical specifications HS-6017 model EU DECLARATION OF CONFORMITY Manufacturer: GIRBAU S.A. Address: Ctra. de Manlleu, km 1, 08500 Vic, Barcelona, SPAIN Identification of the machine Generic denomination: Function: Type: Washer extractor Washing in a water bath and extracting textiles Front loading Lavadora –...
  • Page 10 Technical specifications HS-6023 – 1Ph model EU DECLARATION OF CONFORMITY Manufacturer: GIRBAU S.A. Address: Ctra. de Manlleu, km 1, 08500 Vic, Barcelona, SPAIN Identification of the machine Generic denomination: Function: Type: Washer extractor Washing in a water bath and extracting textiles Front loading Lavadora –...
  • Page 11 Technical specifications HS-6023 – 3Ph model EU DECLARATION OF CONFORMITY Manufacturer: GIRBAU S.A. Address: Ctra. de Manlleu, km 1, 08500 Vic, Barcelona, SPAIN Identification of the machine Generic denomination: Function: Type: Washer extractor Washing in a water bath and extracting textiles Front loading Lavadora –...
  • Page 12 Technical specifications HS-6024 model EU DECLARATION OF CONFORMITY Manufacturer: GIRBAU S.A. Address: Ctra. de Manlleu, km 1, 08500 Vic, Barcelona, SPAIN Identification of the machine Generic denomination: Function: Type: Washer extractor Washing in a water bath and extracting textiles Front loading Lavadora –...
  • Page 13 Technical specifications HS-6028 model EU DECLARATION OF CONFORMITY Manufacturer: GIRBAU S.A. Address: Ctra. de Manlleu, km 1, 08500 Vic, Barcelona, SPAIN Identification of the machine Generic denomination: Function: Type: Washer extractor Washing in a water bath and extracting textiles Front loading Lavadora –...
  • Page 14 Technical specifications HS-6032 model EU DECLARATION OF CONFORMITY Manufacturer: GIRBAU S.A. Address: Ctra. de Manlleu, km 1, 08500 Vic, Barcelona, SPAIN Identification of the machine Generic denomination: Function: Type: Washer extractor Washing in a water bath and extracting textiles Front loading Lavadora –...

  • Page 15: Installation Specifications

    MAXIMUM THERMAL SHOCK ºC (F) 90 (162) 90 (162) 90 (162) MAXIMUM SOUND LEVEL < 70 < 70 < 70 PROTECTION INDEX HS-6024 HS-6028 HS-6032 UNITS EH060 EH070 EH080 DRUM VOLUME dm3 (cu. ft) 239 (8.4) 280 (9.9) 320 (11.3) DRY LINEN CAPACITY kg 1/10 (lbs.)
  • Page 16 Technical specifications Connections HS-6013 HS-6017 HS-6023 UNITS EH030 EH040 EH055 CONNECTION B.S.P 2 x 3/4 (*1) 2 x 3/4 2 x 3/4 thread (NH) mm (in) 1141 (44.9) 1232 (48.5) 1267 (49.9) MIN/MAX PRESSURE bar (P.S.I) 0.5-6 (7-87) 0.5-6 (7-87) 0.5-6 (7-87) RECOMM.
  • Page 17 Technical specifications HS-6024 HS-6028 HS-6032 UNITS EH060 EH070 EH080 CONNECTION B.S.P 2 x 3/4 2 x 3/4 2 x 3/4 thread (NH) mm (in) 1265 (49.8) 1304 (51.3) 1304 (51.3) MIN/MAX PRESSURE bar (P.S.I) 0.5-6 (7-87) 0.5-6 (7-87) 0.5-6 (7-87) RECOMM.
  • Page 18 Technical specifications Legend CONNECTIONS DIMENSIONS (Figures 1, 2 & 3) Water supply Height from the machine base Drain Distance from the centre of symmetry of the unit Electrical connection inlet Depth Electrical connection inlet external dosing Height to door bottom Product inlets external dosing Gravity centre (GC) Steam inlet connection...

  • Page 19: Connection Table Explanation

    Technical specifications Environment and positioning conditions MAXIMUM TEMPERATURE ºC (ºF) +41 (+104) MINIMUM TEMPERATURE ºC (ºF) +5 (+40) LIGHTING VENTING OPENING (sq.ft.) 300 (0.4) MAXIMUM RELATIVE HUMIDITY WORKING AREA mm (in) 1000 (39.4) REAR MAINTENANCE AREA (*3) mm (in) 500 (19.7) *3.

  • Page 20: Electrical Requirements

    Technical specifications 1.6. Electrical requirements Check table explanation in section 1.5. In brackets: USA / CANADA specific values HS-6013 / EH030 TOTAL TOTAL SWITCH CONDUCTOR HEATING (*1) POWER CONSUMP. CURRENT (*2) VOLTAGE (AWG) H / V 0.87 200V 1.5 x 2 + 1ph + N red.
  • Page 21 Technical specifications Check table explanation in section 1.5. In brackets: USA / CANADA specific values HS-6017 / EH040 TOTAL TOTAL SWITCH CONDUCTOR HEATING (*1) POWER CONSUMP. CURRENT (*2) VOLTAGE (AWG) H / V 1.5 x 2 + 200V 1ph + N red.
  • Page 22 Technical specifications Check table explanation in section 1.5. In brackets: USA / CANADA specific values HS-6023 / EH055 3Ph TOTAL TOTAL SWITCH CONDUCTOR HEATING (*1) POWER CONSUMP. CURRENT (*2) VOLTAGE (AWG) H / V 1.75 1.5 x 3 + 200V red.
  • Page 23 Technical specifications Check table explanation in section 1.5. In brackets: USA / CANADA specific values HS-6023 / EH055 1Ph TOTAL TOTAL SWITCH CONDUCTOR HEATING (*1) POWER CONSUMP. CURRENT (*2) VOLTAGE (AWG) 200V 1ph + N H / V 1.75 2.5 x 2 + 208V 1.75 2.5 x 2 +...
  • Page 24 Technical specifications Check table explanation in section 1.5. In brackets: USA / CANADA specific values HS-6024 / EH060 3Ph TOTAL TOTAL SWITCH CONDUCTOR HEATING (*1) POWER CONSUMP. CURRENT (*2) VOLTAGE (AWG) H / V 1.88 2.5 x 3 + 200V red.
  • Page 25 Technical specifications Check table explanation in section 1.5. In brackets: USA / CANADA specific values Connection to power supply Iequ=16A Rsce=250 in accordance with UNE EN 61000-3-12:2012 Z min : (0.165+j0.109) Ohm EN 61000-3-11:2000 HS-6024 / EH060 1Ph TOTAL TOTAL SWITCH CONDUCTOR HEATING (*1)
  • Page 26 Technical specifications Check table explanation in section 1.5. In brackets: USA / CANADA specific values HS-6028 / EH070 3Ph TOTAL TOTAL SWITCH CONDUCTOR HEATING (*1) POWER CONSUMP. CURRENT (*2) VOLTAGE Type mm2 (AWG) 2.5 x 3 + 200V 14.7 42.4 16 x 3 + 2.5 x 3 +...
  • Page 27 Technical specifications Check table explanation in section 1.5. In brackets: USA / CANADA specific values HS-6032 / EH080 3Ph TOTAL TOTAL SWITCH CONDUCTOR HEATING (*1) POWER CONSUMP. CURRENT (*2) VOLTAGE Type mm2 (AWG) 12.1 2.5 x 3 + 200V 14.7 42.4 16 x 3 + 2.5 x 3 +...

  • Page 28: Receipt, Transport And Location

    Transport and location 2. RECEIPT, TRANSPORT AND LOCATION 2.1. Receipt The following should be checked on accepting delivery of the washer: • Check that the product has not suffered any damage in transit. (Any damage caused in this way will not be attributable to the manufacturer, and the appropriate claim should be made against the party responsible for transporting the product.) Check that the delivered machine fulfils the requirements requested in the order: MODEL, VOLTAGE,...

  • Page 29: Safety Door Unlock (Hs-6023, Hs-6024, Hs-6028, Hs-6032, Eh055, Eh060, Eh070, Eh080 Models Only)

    Transport and location 2.3. Safety door unlock (HS-6023, HS-6024, HS-6028, HS-6032, EH055, EH060, EH070, EH080 models only) To open the door in case of power failure, completely insert a rod of a diameter of 0.2 in (3 mm) and an approximate length of 4 inches (100 mm) into the bottom side of the safety lock cover, and at the same time turn the knob downwards.
  • Page 30 Transport and location TO REDUCE VIBRATION AND SOUND AND TO ENSURE THAT THE MACHINE IS CORRECTLY BALANCED, IT IS ESSENTIAL THAT THE FOUR BASE LEGS OF THE WASHING MACHINE REST UNIFORMLY UPON THE FLOOR. DO NOT PLACE ANY TYPE OF ANTI-VIBRATORY DEVICE BETWEEN THE WASHER AND THE FLOOR.

  • Page 31: Installing More Than One Washer

    Transport and location 2.5. Installing more than one washer If the installation calls for more than one washer, align them with each other. The minimum distance between adjacent machines and the user and maintenance areas (values I, S and T of Figure 2.3) are specified on the table below.

  • Page 32: Removal Of Shipping Braces

    PEOPLE AND IRREPARABLE DAMAGES TO THE WASHER. THE WARRANTY DOES NOT COVER THIS INCIDENCE. 2.6.1. HS-6013, HS-6017, HS-6024, HS-6028, HS-6032, EH030, EH040, EH060, EH070, EH080 models Steps to follow (Fig. 2.4 and 2.5). Disassemble the lower cover A, by removing screws B.

  • Page 33: Hs-6023, Eh055 Models

    Transport and location 2.6.2. HS-6023, EH055 models • Remove the screws (Fig. 2.6/A) holding the lower front cover and loosen the three screws (Fig. 2.6/B) holding the base of the chassis. Separate the rubber profile (Fig. 2.6/C) at the two small side guards and remove the front cover •...

  • Page 34: Installation

    Installation 3. INSTALLATION ALL CONNECTIONS FOR ELECTRICAL POWER AND PLUMBING MUST COMPLY WITH THE STATUTORY SAFETY STANDARDS APPLICABLE TO EACH COUNTRY, AND BE MADE BY AUTHORISED INSTALLATION CONTRACTORS ONLY. ALL THE WASHER CONNECTIONS MUST BE CARRIED OUT BY THE AUTHORIZED TECHNICAL SERVICE.
  • Page 35 Installation Direct connection of the washer drain to the manifold (Fig. 3.3) Facilities preferring this option to the open box option (recommended option) must respect the following precautions: Provide next to the connection point of each machine to the manifold, with a manifold ventilation outlet A reaching the outside, set at a height of 40 in (1000 mm) and of a diameter of 2 in (50 mm).

  • Page 36: Water Supply

    Installation 3.2. Water supply IMPORTANT! The local or national regulations concerning the water supply system in the country where the washing machine is installed must be followed. Hoses and pipes should be flushed through before being connected to the machine. Install at each water supply and in an accessible location, a mechanically interlocked water valve.
  • Page 37 Installation Assembling the connection couplings for AUSTRALIA IMPORTANT 20mm dual check valve supplied with machine must be installed on the cold water inlet to the machine. This valve is designed to prevent cross connection (back siphonage) and complies with AS/NZS Standard 2845.1 (Watermark) •...

  • Page 38: Electrical Connection

    CONNECTED TO THE GROUND INSTALLATION WITH A CONDUCTOR CONNECTED TO THE EQUIPMENT GROUNDING TERMINAL. HS-6013, HS-6017, EH030 AND EH040 GIRBAU WASHING MACHINES ARE DESIGNED TO OPERATE IN SINGLE-PHASE AND THREE-PHASE LINES. MODELS OF VOLTAGE BETWEEN 380 AND 415 V REQUIRE IN ADDITION A CONNECTION TO THE NEUTRAL WIRE.

  • Page 39: Machine Electrical Connection

    Installation Safety switch. Install an Automatic on/off Switch, outside the washer, with individual protection for each machine. Characteristics: number of poles and intensity: consult ELECTRICAL CONNECTION table (section 1.5) • • C type with top opening greater than 0.12 in (3 mm) •...

  • Page 40: Transformer Connection. Configuring The Machine Voltage

    Installation 3.3.4. Transformer connection. Configuring the machine voltage HS-6013/HS-6017 models Disconnect and mechanically lock the external automatic switch. • Remove the support cover (A) from the junction box located on the rear panel (Fig. 3.8). • Connect the voltage selector (B) onto the transformer connector (C) in accordance with the power supply •...
  • Page 41 Installation HS-6024/HS-6028/HS-6032 models Disconnect and mechanically lock the external automatic switch. • Open the machine’s top cover. • Connect the voltage selector switch (Fig. 3.10) in accordance with the mains power supply and the following • table (Table 2). Fig. 3.9...

  • Page 42: Steam Connection

    Installation 3.4. Steam connection In some models the body of the steam solenoid valve and the filter are shipped inside the drum of the washing machine, separate from the electrical wiring system. The coil is connected to the end of the electrical installation. In other models, the assembly solenoid valve and filter are supplied connected to the electrical wiring system.

  • Page 43: External Dosing Electrical Connection

    (not supplied with the washer) to fasten the cable or cable pipe protector, depending on the cable and pipe protector used. Refer to dimensions and connection diameter in INSTALLATION SPECS, section 1.4. In models HS-6024/HS-6028/HS-6032 and EH060/EH070/EH080, secure the conductor using the cable ties •...
  • Page 44 Installation 3.5.1.d. Dosing equipment connection. RELAY CONTACTS POWERED FROM THE WASHER CONTROL CIRCUIT. (Fig. 3.14) IMPORTANT This connection allows for the maximum strength at each of the 50mA outputs. Higher consumption can prevent the washer from functioning correctly. This connection can aggravate any problems produced by a fault in the grounding connection, both of the washer itself and of the external dosing equipment.

  • Page 45: External Dosing Hoses Connection

    Installation 3.5.2. External dosing hoses connection The external dosing inlets are perforated and protected by a tube cap. Refer dimensions dosing inlets diameter INSTALLATION SPECS, section 1.4. To connect the product cables: Locate the dosing inlets in the back of the machine. •...

  • Page 46: External Signal. Connection

    HS-6023 18 mm (0.71 in) 20 mm (0.79 in) EH055 HS-6024 9 mm (0.35 in) 10 mm (0.39 in) EH060 HS-6028 9 mm (0.35 in) 11 mm (0.43 in) EH070 HS-6032 9 mm (0.35 in) 11 mm (0.43 in) EH080 Fig.

  • Page 47: Initial Start-Up

    Installation 3.8. Initial start-up THE WASHER MUST BE PUT INTO SERVICE BY AN AUTHORIZED TECHNICAL SERVICE. Before the initial START-UP, make sure that you accomplish the following points: Remove all packing materials. (Break them down in order to appropriately recycle them) •...
