Installation - Direct IP DC-D4538RA Installation Manual

Installation

• Check the wall or ceiling to see if it needs to be
reinforced. The camera may fall off if the wall or
ceiling is not strong enough to support its weight.
• Install the camera in a shaded area. If the camera
is installed in direct sunlight, it may be affected
adversely.
DC-D4538RA
1
Use the screws, anchor provided with the camera to
secure the install bracket on a wall or a ceiling.
Use the provided guide pattern to check the
distance between the screws.
2
Connect external devices, the network cable, and
the power adapter.
3
Adjust the angle. For more information, refer to the
Angle Adjustment.
DC-D4538WRA
(If necessary) Attach one end of the safety wire (not
provided) to the wall or ceiling, and the other end
of the safety wire to the installation location on the
camera body.
Safety Wire Screw (Provided)
Safety Wire (Not Provided)
1
Detach the protrusion part from the cable rubber
along the dotted line.
2
Make the LAN cable go through the cable rubber
using the protect connector.
It is recommended to use lubricant to move the LAN
cable smoothly.
3
Pull the cable slightly and arrange the rubber as
shown below.
Part 1 – Introduction
13
