Specifications - Direct IP DC-D4538RA Installation Manual

Specifications

These product specifications may change without prior notice.
Video
Image Sensor
Max. Resolution
Scanning Mode
Lens type
Focal Length
Aperture
Iris Control
Angular Field of 5M (2592 x
View 1944)
4M (2592 x
1456)
Min. Illumination
Dynamic Range
Electronic Shutter Speed
Day & Night
IR Distance (LEDs)
Pan/Tilt/Rotate Range
Network
Video Compression
Bit rate Control
Max. Frame Rate
Audio Compression
Supported Resolution
Multi-Video Streaming
Ethernet
1/2.8" CMOS
2592 x 1944 (4:3)
2592 x 1456 (16:9)
Progressive Scan
Motorized Vari-focal
f=2.7 - 13.5mm
F=1.4 ~ 3.2
DC Iris
H : 101.2° (WIDE ) ~ 30.4° (TELE)
V : 72.57° (WIDE ) ~ 22.8° (TELE)
D : 137.4° (WIDE) ~ 38° (TELE)
H : 101.7° (WIDE ) ~ 30.2° (TELE)
V : 53.3° (WIDE ) ~ 17° (TELE)
D : 121.6° (WIDE) ~ 34.7° (TELE)
COLOR : 0.13 lux @ F1.4
B/W : 0 lux (IR LED ON)
120dB, True WDR
Auto / Manual (1/30 ~ 1/10,000), Anti-Flicker, Slow Shutter (25 ips: 1/12.5, 1/6.25
30ips: 1/15, 1/7.5)
IR cut filter with auto switch
30m (6ea)
Pan: -175° ~ 175°, Tilt: 0° ~ 60°, Rotate: -177° ~ 177°
H.265, H.264(MP), M-JPEG
CBR / VBR
4:3 mode : 30fps : 2592 x 1944(WDR)
16:9 mode : 30fps : 2592 x 1456(WDR)
G.726, ADPCM-16K, G.711u-Law, G.711a-Law
4:3 : 2592x1944, 1920x1440, 1280x960, 640x480
16:9 : 2592x1456, 1920x1080, 1280x720, 640x360
Quadruple
RJ45(10/100BASE-T)
Part 3 - Appendix
21
