Connecting to the ioThinx 4530 Series Controller
Accessing the ioThinx 4533 Series Using a PC
You can use a PC to access the ioThinx 4533 Series by one of the
following methods:
1. Through the serial console port by the console cable with the
following settings:
Baudrate=115200 bps, Parity=None, Data bits=8, Stop
bits=1, Flow Control=None, Terminal type=VT100.
2. Using SSH over the network.
Refer to the following IP addresses and login information:
Port
LAN1
LAN2
Username: moxa
Password: moxa
NOTE Please prioritize using LAN2 for connecting the ioThinx 4533.
The LAN1 is assigned by DHCP server by default; the link-local
IP addresses will be assigned when the DHCP server is not
available.

Loading the Factory Default Settings

Press and hold the reset button between 7 to 9 seconds to reset the
computer to the factory default settings. When the reset button is held
down, the RDY LED will blink GREEN once every second and become
steady after 7 to 9 seconds. Release the button within this period to
load the factory default settings.
How to Download the Software
Related software packages can be downloaded from the Moxa website.
Step 1: Go to the following address:
https://www.moxa.com/en/support
Step 2: Select a product list from the drop-down box or type the model
name in the search box.
Default IP
DHCP
192.168.4.127
- 9 -
Subnet Mask
DHCP
255.255.255.0
