Specifications - Moxa Technologies ioThinx 4530 Series Quick Installation Manual

Step 3: Go to the Software & Documentation page to download the
latest software for the product.

Specifications

Input Current
Input Voltage
Operating Temperature
Storage Temperature
Attention
1. This device is only for indoor use in environments with pollution
degree 2.
2. This device has field power ground and two ground pins on the
back of the device. For surge protection, connect the field power
ground pin to your field power ground and connect the DIN rail to
earth ground. See pages 3 and 4 for location and wiring
information.
3. Cables rated for a minimum temperature of 120°C must be used
for the power supply terminal.
4. We suggest using the following cable types for wiring:
ioThinx 4530 Series:
• AWG 12 to 16 for power connections (Ferrule diameter: 2.053
mm to 1.291 mm), with 10 mm wire strip length.
• AWG 16 to 28 for serial connections (Ferrule diameter: 1.291
mm to 0.321 mm), with 10 mm wire strip length.
• AWG 12 to 18 for field power ground connections (Ferrule
diameter 2.053 mm to 1.024 mm), with 10 mm wire strip
length.
5. Terminal blocks do not accommodate more than one individual
conductor on a clamping point.
System Power: 1.94 A (Max.)
Field Power: 2 A (Max.)
System Power: 12 to 48 VDC
Field Power: 12/24 VDC
Standard Models:
-20 to 60°C (-4 to 140°F)
Wide Temp. Models:
-40 to 75°C (-40 to 167°F)
-40 to 85°C (-40 to 185°F)
