LED Indicators

Label Usage
System
SP
Power
Field
FP
Power
System
RDY
(kernel)
User
U1/U2
defined
microSD
SD
card
L1/L2 Ethernet
P1/P2 Serial
Connecting to the ioThinx 4530 Series Controller
Use the following configuration information to log in to the ioThinx 4530
Series controller:
Port Default IP
LAN1 192.168.127.254
LAN2 192.168.126.254
• Username: moxa
• Password: moxa
NOTE Be sure to configure the host PC's IP address to use the same
subnet as the unit. For example, 192.168.127.253 for LAN1
port.

Loading the Factory Default Settings

1. Power off the device.
2. Press and hold the reset button; while holding the reset button:
a. Power on the device; the RDY LED will blink green while the
device is booting up.
b. After the device has booted up, the RDY LED will blink red;
continue holding the reset button until the RDY LED stops
blinking.
3. Release the reset button to load the factory default settings.
Qty Color
1 Green
1 Green
1 Green/Red
1 of each Green/Red User-defined
1 Green
Green/
1 of each
Amber
Green/
1 of each
Amber
Subnet Mask
255.255.255.0
255.255.255.0
- 8 -
Action
On: Power on
Off: Power off
On: Power on
Off: Power off
Green: System ready
Green (blinking): System is
booting up
Red: System error, or
executing factory default
Red (blinking): Triggering
factory default, or upgrading
the firmware
Green: SD card is inserted
OFF: SD card is being
accessed
Green: 100Mb
Amber: 10Mb
Blinking: Data is being
transmitted
Off: Inactive
Green: Tx
Amber: Rx
Blinking: Data is being
transmitted
Off: Inactive
