TFinity Transporter Replacement
Figure 33 Position the vertical picker above the upper left mounting screw.
If the hooks are properly engaged with the bracket, the transporter moves left-to-
Important
right slightly. If the hooks are not engaged with the bracket, the transporter pulls
away from the mounting bracket. If the transporter pulls away from the VAX column,
remove the mounting screws, carefully disengage the transporter hooks from the
mounting bracket, and then repeat
November 2018
ii. Rotate the picker to vertical and position the sensor above the
upper left hand mounting screw.
e. While stabilizing the transporter with one hand, gently rock the
transporter from left to right to confirm that both transporter
mounting hooks are resting equally and securely seated in the slots
on the mounting bracket.
Transporter Replacement—Spectra TFinity Library
Step 2.
Install the Transporter
