TFinity Transporter Replacement
2. Remove the lower cover panel on the end of the service frame to
November 2018
provide access to the transporter in the service bay. See
page 14 for the location of the cover panel.
a. From the open service access bay, use a #2 Phillips screwdriver to
remove the two screws that secure the lower cover panel to the
chassis.
Figure 13 Remove the screws securing the lower cover
panel to the chassis.
b. Slide the lower cover panel toward the back of the library to remove it.
Figure 14 Slide the lower cover panel off.
Transporter Replacement—Spectra TFinity Library
Remove the Transporter
Figure 12 on
Screw (2)
Rails
