TFinity Transporter Replacement
4. Click Close Door next to the robot that is in its service bay ready for the
Close the service bay safety door, as described in
Important
prior to clicking
5. Continue with

Close the Service Bay Safety Door

The manually operated service bay safety door slides closed to isolate the
TeraPorter in the service bay, making it possible to continue library
operations while you service the TeraPorter. Use the following steps to
physically close and lock the service bay safety door.
There are three doors on the back of the service frame. Only open the full-length
Important
door, shown in
Do not open the service access door until after the service bay safety door is closed. A
safety interlock on this door immediately turns off the 24 VAC power to the TeraPorter,
which will prevent the other TeraPorter from performing backup operations.
1. Lift and rotate the latch on the full-length access door on the service
November 2018
service operation. The library disengages the solenoid lock on the
service bay safety door so that it can be closed. Directions to close and
lock the service bay safety door display.
OK
.
Close the Service Bay Safety
Figure 6, which provides access to the service bay safety door.
frame where the TeraPorter is parked, then pull the door open.
You may need to unlock the latch before you can open it.
Note:
Figure 6 Open the full-length service frame access door
(service frame for Robot 2 shown).
Transporter Replacement—Spectra TFinity Library
Prepare to Replace the Transporter
Close the Service Bay Safety
Door.
Full-length access door
Service access door
Do NOT open this door until after
the safety door is closed.
Door,
