TFinity Transporter Replacement
6. After you install the transporter, skip to

Install the Transporter - Robot 2

1. With one hand supporting the weight of the transporter from
Do not lift the transporter using the cartridge picking mechanism or the front of
Caution
the transporter (see
weight of the transporter.
November 2018
b. Using a #2 Phillips screwdriver, install the two screws that secure
the lower cover panel to the chassis.
Figure 31 Install the screws to secure the lower cover
panel to the chassis.
c. Close the lower service access door and then rotate the latch to its
vertical position, latching the door closed (see
page 34.
underneath and your other hand stabilizing it, orient the transporter
with the bracket hooks toward the mounting bracket on the VAX
column (see Figure 23
Figure 1 on page
Transporter Replacement—Spectra TFinity Library
Complete the Replacement on
and Figure 24 on page
5). They are not designed to support the
Install the Transporter
Screw (2)
Figure 12 on page
23).
14).
29
