TFinity Transporter Replacement
4. Using a 5/32-inch Allen wrench or T-handle hex wrench, remove the
Keep the screws from dropping into the transporter or onto any of the internal
Caution
library components. If you drop any screws, they must be located prior to placing
the robot back into service.
Figure 16 Remove the screws securing the transporter to the mounting bracket on the VAX column.
5. With one hand supporting the weight of the transporter from
Do not lift the transporter using the cartridge picking mechanism or the front of
Caution
the transporter (see
weight of the transporter.
November 2018
four screws that secure the transporter to the mounting bracket on the
VAX column.
underneath and the other hand stabilizing it, lift the transporter
upward approximately 2 inches (5 cm) and then to the left to disengage
it from the mounting bracket on the VAX column.
Figure 1 on page
Transporter Replacement—Spectra TFinity Library
5). They are not designed to support the
Remove the Transporter
17
