Server specifications

Components

Figure 1 Server components
Item
(1) Chassis access panel
(2) Storage controller
(3) Standard
adapter
(4) SATA M.2 SSD
(5) Chassis open-alarm module
(6) SATA M.2 SSD expander
module
(7) OCP 3.0 network adapter
(8) Riser card blank
(9) GPU module
(10) Encryption module
Description
N/A
Provides RAID capability to SAS/SATA drives, including RAID
configuration and RAID scale-up. It supports online upgrade of the
controller firmware and remote configuration.
PCIe network
Installed in a standard PCIe slot to provide network ports.
Provides data storage space for the server.
Detects if the access panel is removed. The detection result can be
displayed from the HDM Web interface.
Provides M.2 SSD slots.
A type of network adapter, which must be installed in an OCP riser
module on the system board.
Installed when a riser card is absent on the system to ensure good
ventilation
Provides computing services such as graphics processing and AI.
Provides encryption services for the server to enhance data security.
