HDDs and SSDs

Drive numbering

Drive numbers are used to indicate the drive positions, which are completely consistent with the
marks on the front and rear panels of the server.
For the correspondence between the drive numbering of physical drives on the server and the drive
numbering on HDM or BIOS, see H3C UniServer R6900 G6 Server Drive Configurations and
Cabling Solutions.
Figure 12 Drive numbering at the server front
Figure 13 Drive numbering at the server rear

Drive LEDs

The server supports SAS, SATA, and NVMe drives. You can use the LEDs on a drive to identify its
status.
Figure 14 and
Figure 14 LFF&SFF drive LEDs
Figure 15 shows the location of the LEDs on a drive.
