Product specifications

Technical specifications

Item
Processors
Chipset
Integrated
graphics
Memory
Storage
controllers
FBWC
Storage
Network
Expansion
slots
Connectors
GPUs
Specifications

4 × Intel ® Xeon ®
supports up to 60 cores and up to 350 W power consumption per processor

Supports Montage Jintide processors
Intel C741 Emmitsburg chipset
The graphics chip (model AST2600) is integrated in the BMC management chip to provide
a maximum resolution of 1920 × 1200@60Hz (32bpp), where:

1920 × 1200: Specifies 1920 pixel columns horizontally and 1200 pixel columns
vertically.

60Hz: Specifies the refresh rate, which is 60 screen refreshes per second.

32bpp: Specifies the color bit depth. The higher the color bit depth, the more rich and
vibrant the displayed colors.
When both the front and rear VGA ports are connected to monitors simultaneously, only the
monitor connected to the front panel VGA port will display.
Supports a maximum of 64 DIMMs. DDR5 DIMMs are supported.

Embedded VROC storage controller.

High-performance storage controllers

NVMe VROC module

Serial & DSD module: Supports RAID 1
p to 8 GB cache, supporting the supercapacitor
U

Supports SAS/SATA HDD/SSD drives

(Optional.) U.2 NVMe drives. The PCIe NVMe storage accelerator is supported.

Supports dual-M.2 module (hot swapping supported)

1 × embedded 1 Gbps dedicated network port

(Optional.) 4 × 1GE copper interfaces, 2 × 10GE copper interfaces, or 2 × 25GE fiber
interfaces through the OCP 3.0 x16 open interface.

(Optional.) Network
1/10/25/40/100/200 GE network adapters and IB cards.

Up to 10 × standard x16 PCIe5.0 slots

Up to 22 × standard x8 PCIe5.0 slots

Up to 2 × OCP3.0 riser module connectors

Up to six USB connectors (two on the system board, two on the rear panel, and two on
the front panel)

Built-in 10 SATA connectors (displayed as two x4 SlimSAS connectors and one GenZ
connector)

Built-in 32 MCIO connectors (PCIe5.0 x8)

One RJ-45 HDM dedicated network port (on the rear panel)

Two VGA connectors (one on the rear panel and one on the front panel)

One serial port (available only when the Serial & DSD module is used)

One dedicated management port (on the front panel, available only when the left
chassis ear is installed)
Up to 6 dual-width GPU modules or 10 single-width GPU modules
scalable processors of the fourth generation. Each processor
adapters in standard
0
PCIe slots, with support for
