Item
7
8
9
10
11
12
13
14
For more information about the serial & DSD module, see

LEDs

Figure 6 Rear panel LEDs
(1) Power supply LED for power supply 2
(3) Activity LED of the Ethernet port
(5) UID LED
Table 6 LEDs on the rear panel
LED
UID LED
Link LED of the Ethernet port
Description
Power supply 3
Power supply 1
OCP 3.0 network adapter/Serial & DSD module (in slot 24) (optional)
VGA connector
Two USB 3.0 connectors
HDM dedicated network port (1Gbps, RJ-45, default IP address 192.168.1.2/24)
OCP 3.0 network adapter (in slot 23) (optional)
Serial label pull tab
Status
Steady blue—UID LED is activated. The UID LED can be activated by
using the following methods:
Press the UID button LED.
Enable UID LED from HDM.
Flashing blue:
1 Hz—The firmware is being upgraded from HDM in an out-of-band
manner or the system is being managed from HDM. Do not power
off the server.
4 Hz—HDM is restarting. To restart HDM, press the UID button LED
for at least 8 seconds.
Off—UID LED is not activated.
Steady green—A link is present on the port.
6
"Serial & DSD
module."
(2) Power supply LED for power supply 1
(4) Link LED of the Ethernet port
