Processor system board

Processor system board components

Figure 7 Processor system board components
Table 8 System board components
No.
1
2
3
Description
OCP riser module connector 2/Serial & DSD module connector
Fan connector for OCP 3.0 network adapter 2
TPM/TCM connector
8
Mark
OCP2
OCP2 FAN
TPM
