H3C UniServer R6900 G6 Technology White Paper page 16

No. Description
4 PFR expander module connector
5 Server management module connector
6 PCIe riser connector 1 (x16 PCIe5.0, for processor 1)
7 Fan connector for OCP 3.0 network adapter 1
8 OCP riser module connector 1
9 SlimSAS connector 2 (x4 SATA)
10 SlimSAS connector 1 (x4 SATA)
11 M.2 connector (x2 SATA)
12 NVMe VROC module connector
13 Front I/O connector
14 Built-in USB 2.0 connector
15 System battery
16 MCIO connector C1-P1C (x8 PCIe5.0, for processor 1)
17 MCIO connector C1-P1A (x8 PCIe5.0, for processor 1)
18 MCIO connector C1-P3A (x8 PCIe5.0, for processor 1)
19 MCIO connector C1-P3C (x8 PCIe5.0, for processor 1)
20 MCIO connector C1-P4C (x8 PCIe5.0, for processor 1)
21 MCIO connector C1-P4A (x8 PCIe5.0, for processor 1)
22 AUX connector 3 for the front drive backplane
23 AUX connector 2 for the front drive backplane
24 Power connector 5 for the front drive backplane
25 LCD smart management module connector
26 Temperature sensor connector
27 Power connector 3 for the front drive backplane
28 Power connector 6 for the front drive backplane
29 AUX connector 5 for the front drive backplane
30 AUX connector 6 for the front drive backplane
31 AUX connector 4 for the front drive backplane
32 MCIO connector C2-P4A (x8 PCIe5.0, for processor 2)
33 MCIO connector C2-P4C (x8 PCIe5.0, for processor 2)
34 Power connector 4 for the front drive backplane
35 MCIO connector C2-P3C (x8 PCIe5.0, for processor 2)
36 Power connector 1 for the front drive backplane
37 MCIO connector C2-P3A (x8 PCIe5.0, for processor 2)
38 Power connector 2 for the front drive backplane
39 AUX connector 1 for the front drive backplane
40 Chassis open-alarm module connector
9
Mark
PFRCPLD
BMC
RISER1 PCIe X16
OCP1 FAN
OCP1
SATA PORT2
SATA PORT1
M.2 PORT
NVMe RAID KEY
RIGHT EAR
INTERNAL USB2.0
N/A
C1-P1C
C1-P4A
C1-P3A
C1-P3C
C1-P4C
C1-P4A
AUX3
AUX2
PWR5
DIAG LCD
SENSOR1
PWR3
PWR6
AUX 5
AUX 6
AUX 4
C2-P4A
C2-P4C
PWR4
C2-P3C
PWR1
C2-P3A
PWR2
AUX1
INTRUDER
