PCIe5.0 x16 (8,4) description:

PCIe5.0: Fifth-generation signal speed.

x16: Connector bandwidth.

(8,4): Compatible bus bandwidth, including x8 and x4.
NOTE:
slot 2/9: When the riser card is installed in PCIe riser card slot 1, this slot corresponds to PCIe slot 2.
When the riser card is installed in PCIe riser card slot 2, this slot corresponds to PCIe slot 9. This rule
applies to all the other PCIe riser card slots. For information about PCIe slots, see

RC-4HHHL-R3-4U-G6

Figure 27 RC-4HHHL-R3-4U-G6 riser card
Table 16 RC-4HHHL-R3-4U-G6 riser card description
No.
1
2
3
4
5
6
PCIe5.0 x16 (8,4) description:

PCIe5.0: Fifth-generation signal speed.

x16: Connector bandwidth.

(8,4): Compatible bus bandwidth, including x8 and x4.
Description
PCIe5.0 x16 (16,8,4) slot 2/9
MCIO connector 4-A
MCIO connector 2-A
MCIO connector 4-C
MCIO connector 2-C
Description
PCIe5.0 x16 (8,4) slot 18
PCIe5.0 x16 (8,4) slot 17
GPU power connector 1
AUX connector
PCIe5.0 x16 (8,4) slot 16
PCIe5.0 x16 (8,4) slot 15
23
